Paper Roll to Sheet Automatic Sheet Feed Die Cutting Machine
| Place of Origin | Guangdong, China |
| Brand Name | Robotsung |
| Certification | CE |
Paper Roll To Sheet Automatic Sheet Feed Die Cutting Machine
1.Cutting width :0.1-300mm
2.Cutting thickness;0.1-21mm
3.Cutting length:0.1-9999.9mm
Features:
- High speed: It can cut 100~120 cut per minute. (50mm long)
- Accuracy: Cut-length is accurate cwing to a stepping motor
- Cutting type: Cutting is neat due to using a cold cutter which is durable.
- Automatic operation: It works auto only by setting length and quantity
- Automatic stopper: It stops auto if materials run out during operation
- Memory: Set-length, set-q'ty & set-speed are not erased even if power off & on
- Application: Weave belt, nylon buckle, lining and don't need to heat the sealing ribbon, plastic zippers, shoes webbing, etc.
- Freature: Heavy duty, high speed, high accuracy, designed for cutting non-adhesive materials.
Specifications:
YS-300W
Available Width: 0.1 ~ 300mm
Available Thickness:0.1-10mm
Available Length: 0.1 ~ 99999mm
Knife: Cold cutting/Hot Cutting (For option)
Speed: 120pcs/min
Accuracy: ± 0.1mm
Power Supply: AC110V 60Hz / AC220V 50Hz 500W (Convertible)
Measurement & Weight: 36*30*35cm(28kg)
Materials can cut:
Cutting Machine parts show:
More details:
Shipping Parts:
Shipping & Package:
By DHL,Fedex,TNT,UPS or special line.
For packing size and weight,please contact sales
We provide:
*Leadtime:within 3 days after receiving payment
*One year Warranty
*OEM and customized service
*High quality and factory price
We guarantee:
*Every machine has been tested before shippment.Machine testing video can be sent
