Fully Automatic Nut Tightening Machine Automatic Nut Bolt Screwing Machine
|
Fully Automatic Nut Tightening Machine Automatic Nut Bolt Screwing Machine
| Place of Origin | Guangdong, China |
| Brand Name | Robotsung |
Product Details
Weight (kg):
90
Video Outgoing-inspection:
Provided
Machinery Test Report:
Not Available
Core Components:
Motor
Warranty:
1 Year
Power(W):
0.36KW
Voltage:
220 V, 110 V, 220V/110V
Product Name:
Automatic Nut Bolt Screwing Machine
Application:
Automation Equipment
Model:
YS-L:542
Delivery Time:
7 Business Days
Power:
380W
Package:
Wooden Case
Size:
680*750*700
After-sales Service Provided 1:
Online After Sale Service
Payment & Shipping Terms
Minimum Order Quantity
1 set
Price
$2,700-2,800 / set
Product Description
Products Description
Advantages
1,High efficiency, the blowing screw directly sends the screw to the batch nozzle, saving the time of taking the screw back and
forth, and the efficiency is higher and more stable.
2,Reduce the labor intensity of workers. Workers only need to pick and place the product and the machine can automatically
complete the screwing, which greatly reduces the labor intensity.
3,Simple operation. The display screen can be operated visually, and the staff can quickly grasp the operation and debugging. One
worker can manage several machines at the same time.
4,Improve product quality: accurate torque, convenient adjustment, and guarantee the quality of locking.
5. Stable performance, with leakage detection function, it will appear that individual screws have not been blown into place at a time, and can continue to blow or alarm processing to reduce product leakage of screws and increase product qualification rate.
Application
Suitable for all types of screws the total length of the screw should be greater than 1.3 times the diameter of the nut. Screws
with a total length of no more than 40mm can be fitted with removable gaskets.
forth, and the efficiency is higher and more stable.
2,Reduce the labor intensity of workers. Workers only need to pick and place the product and the machine can automatically
complete the screwing, which greatly reduces the labor intensity.
3,Simple operation. The display screen can be operated visually, and the staff can quickly grasp the operation and debugging. One
worker can manage several machines at the same time.
4,Improve product quality: accurate torque, convenient adjustment, and guarantee the quality of locking.
5. Stable performance, with leakage detection function, it will appear that individual screws have not been blown into place at a time, and can continue to blow or alarm processing to reduce product leakage of screws and increase product qualification rate.
Application
Suitable for all types of screws the total length of the screw should be greater than 1.3 times the diameter of the nut. Screws
with a total length of no more than 40mm can be fitted with removable gaskets.
Machine Structure | weight | 60kg |
size | 880*770*680cm | |
Working area | 250*400*100mm*2 | |
Power | 220/110V,50/60HZ | |
Air pressure | 0.4-0.6MPA | |
Material | made of aluminum profiles | |
Drive | Closed loop stepper motor and Hiwin guide rail | |
Feeder | Quantity | 1 PCS |
Feeding type | suction type | |
Screw size | M1-M6 | |
Screw driver | Brand | HHB or KILEWS |
Function | Torque detection | yes |
Slippery detection | yes | |
screw leakage detection | yes |
Screw feeder
Suction type rotation screw feeder
Screw driver
Brand HHB or KILEWS made in Taiwan
Brushless electric batch
It will stop automaticly when torque reach which protect the screw and products.
Model No. | YS-L542 | ||
Machine structure | Weight | About 80Kg | |
Dimension | 680 Length*750 Width*700Height mm) | ||
Working Area | 500*300*300*100 | ||
AC | AC 220V 50HZ/AC 110V 60HZ | ||
Power | 360W | ||
Air source | >0.5MPa | ||
Gas consumption | 10m3/hour | ||
rame | High quality aluminum profile structure | ||
Drive mode | Closed loop stepper motor + silver guide rail | ||
Control instructions | Host program control | Robotsung control system | |
Human-computer interface | LCD screen, display and adjust various parameters, 5.7-inch touch screen | ||
Screw feeding machine | Automatic nail feeding machine | Place on the machine rack | |
Automatic nail feeding machine quantity | 1PC | ||
Screw introduction method | adsorption type | ||
Applicable screw range | M1-M6 | ||
screwdriver | Electric screwdriver | Can be selected according to customer requirements | |
Scope of application | Applicable product size | Customized according to customer product size specifications (can be adjusted arbitrarily within the customization range) | |
vertical adjustment range | Customized according to customer products | ||
Screw tightening depth | Customers set by themselves | ||
Test items | Electric screwdriver torque detection | Yes | |
Screw thread detection | Yes | ||
Screw leakage detection | Yes | ||
Model No. | YS-L542 | ||
Machine structure | Weight | About 80Kg | |
Dimension | 680 Length*750 Width*700Height mm) | ||
Working Area | 500*300*300*100 | ||
AC | AC 220V 50HZ/AC 110V 60HZ | ||
Power | 360W | ||
Air source | >0.5MPa | ||
Gas consumption | 10m3/hour | ||
rame | High quality aluminum profile structure | ||
Drive mode | Closed loop stepper motor + silver guide rail | ||
Control instructions | Host program control | Robotsung control system | |
Human-computer interface | LCD screen, display and adjust various parameters, 5.7-inch touch screen | ||
Screw feeding machine | Automatic nail feeding machine | Place on the machine rack | |
Automatic nail feeding machine quantity | 1PC | ||
Screw introduction method | Air blowing | ||
Applicable screw range | M1-M6 | ||
screwdriver | Electric screwdriver | Can be selected according to customer requirements | |
Scope of application | Applicable product size | Customized according to customer product size specifications (can be adjusted arbitrarily within the customization range) | |
vertical adjustment range | Customized according to customer products | ||
Screw tightening depth | Customers set by themselves | ||
Test items | Electric screwdriver torque detection | Yes | |
Screw thread detection | Yes | ||
Screw leakage detection | Yes | ||
Model No. | YS-L542 | ||
Machine structure | Weight | About 80Kg | |
Dimension | 680 Length*750 Width*700Height mm) | ||
Working Area | 500*300*300*100 | ||
AC | AC 220V 50HZ/AC 110V 60HZ | ||
Power | 360W | ||
Air source | >0.5MPa | ||
Gas consumption | 10m3/hour | ||
rame | High quality aluminum profile structure | ||
Drive mode | Closed loop stepper motor + silver guide rail | ||
Control instructions | Host program control | Robotsung control system | |
Human-computer interface | LCD screen, display and adjust various parameters, 5.7-inch touch screen | ||
Screw feeding machine | Automatic nail feeding machine | Place on the machine rack | |
Automatic nail feeding machine quantity | 1PC | ||
Screw introduction method | Air blowing | ||
Applicable screw range | M1-M6 | ||
screwdriver | Electric screwdriver | Can be selected according to customer requirements | |
Scope of application | Applicable product size | Customized according to customer product size specifications (can be adjusted arbitrarily within the customization range) | |
vertical adjustment range | Customized according to customer products | ||
Screw tightening depth | Customers set by themselves | ||
Test items | Electric screwdriver torque detection | Yes | |
Screw thread detection | Yes | ||
Screw leakage detection | Yes | ||
Applications
Exhibition
Factory Show
Certifications
Product packaging
FAQ
Pre-sale guide
Q:MOQ?
A:one set.
Q:can make it 110V?
A:YES.
Q:Can you ship it to my agent in China?
A:YES.
Q:Warranty?
A:One year.
Q:Lead time?
A:It need 5-7 days after payment receive.
Q:Do you accept credit card?Can we order it by alibaba?
A:Yes,credit card,Paypal are welcomed.Support buy machine from alibaba.
Q:Can you provide the tranportation for us?
A:Yes,provide shipping cost by express,by air and by sea for your option.
